Recommended best practices and considerations.
See the SchemaTongs Walkthrough to help you get started with the tool.
gold copy and extract it to create an initial product.true up each
one is critical. You may find changes that you want to add to or remove from your template
during this comparison process.
We strongly recommend that each object file, whether it is table JSON or a SQL file for other objects,
be named with the schema and object name. This will make them simpler and easier to locate in your
source control when you need to make changes. Our examples will use the form
< schema >.< object name >.ext, but you could use
spacing or underscores if you prefer or follow a different convention altogether. It is your schema...
your source code... you should tailor your repository to meet your needs.
For scripted (.sql) items, we strongly recommend using CREATE OR ALTER in your script so that
they can be applied safely every time. This keeps all the objects trued up with every release
and helps to eliminate the drift that can creep in overtime. The management of dependencies for
scripted objects is left up to the script to manage. Things such as dropping a computed column
that references a function that is being updated. This allows you to decide the correct way to
manage it. If the function is rarely changed, then perhaps the script should become
"create when not exists" rather than using the CREATE OR ALTER approach.
If the object tends to change often, then you can script the removal of such dependencies.
Dropping a computed column or constraint is generally all you would need because the
objects will be applied prior to table updates and the missing items would then be restored
automatically by SchemaQuench.
For triggers, we strongly recommend using a naming convention of < schema >.< table name >.< trigger name >.sql
to keep them grouped by table. An alternative approach could be to create folders for each table
and put the triggers in the correct folder and simply use < trigger name >.sql.
Whatever makes it easier to find and update the object later.
SchemaTongs will follow our recommended naming conventions and the basic folder layout. You are free to rename and group the files it generates for your repository, but keep in mind that the tool will not understand those changes. Rerunning the tool will recreate the files with the original folder structure and naming again, and you will need to modify the names and locations to update the repository.
We have defined the folder structure for each template, divided into the basic object types we support in SchemaTongs and adding the ability to define before and after migration scripts to do any special handling like:
Anything that might need to happen outside the main flow of the update either at the beginning or the end of the database update. There is also a folder for data delivery scripts to help you in the delivery of seed data.
All of these folders support the addition of subfolders to allow grouping objects into domains or any other logical organization that simplifies your development efforts. Even the Tables folder can have subfolders to organize your tables into logical groupings when the model gets complex enough that you want to break it down.
Using the SchemaSmithy allows you to break your database schema into easily located and identified pieces that can be placed in source control as text files just like any other source code. You can then begin to monitor and observe the changes and evolution of your schema just as you do with your application code base. You can also choose to place your SchemaSmithy project directly in a folder in your main source control project so that database changes become atomic with the code. Some teams use this approach and some prefer to have the database changes remain separate with a different rollout cadence. That flexibility is completely in your hands.
From this point your schema changes will be straightforward to see and track via source control like your other source code. See Examining The Product Repository Structure for information on how the files will be laid out on disk. Socialize this new process and have people begin making changes here rather than your previous location.
It is strongly recommended to start with gatekeepers, code owners in git, who must approve pull requests to ensure the new repository is being used correctly. In the beginning, you may need both the old and new system as you migrate to this approach and slowly clean up the drift. The same group should be approving all changes going into the old and new repositories to ensure changes are checked into the correct location.
Some organizations have database changes restricted to a small group of experienced and trained
database developers and/or DBAs. While it is good to have oversight, it can create a bottleneck
on getting changes done for multiple project streams running concurrently. SchemaSmithy can allow
opening up the ability for anyone to check in changes and make pull requests while keeping oversight
and approval still in the hands of that smaller group. Project startups and designs can still involve
those individuals to ensure a cohesive database design. The process of incremental changes can then
move down to developers with the core group only tasked with making sure proper guidelines are followed
and nothing is veering outside agreed design parameters. Needing an extra three characters on a
VARCHAR column does not have to pull someone into a meeting or create extra tickets
with dependencies that block other coding work waiting for an additional resource to make the change.
Most column changes are as simple as making the type or property adjustment (length, type, nullability, etc.), and SchemaQuench handles the rest. We drop dependent constraints and indexes and recreate them as needed so the developer and reviewer can focus on the specific change, not the cascade of actions that might be required to perform it. CI should catch any edge cases that we might not handle, and you can always create migration scripts for any special conditions you might need to handle specific to your environment.
We recommend running CI for every PR. Catch issues early and fix them before they cause downstream impacts. The same principles that apply to your code apply to your structure. Test early, test often, fix problems and move forward with confidence. It is recommended that you apply to existing databases with representative types of data. Some issues only arise when data is present, such as altering data types when the data does not conform to the new type or is too long to fit in a truncated length. Just like any other code, you need human review and the double check of testing to keep your quality high and your customer impacts low.
It is also advisable to use something like Docker or other local setup to test applying your product
on completely empty databases. This helps make sure that you include all the objects you
need in the repository and that you can start a fresh environment when you need one. Too often, dependencies
creep in overtime. For example, a "before" migration script gets added that needs an object that would not
exist yet in a clean run. Those scripts should be protected against failing in the case of an initial
deployment. It is valuable to test that condition regularly to maintain that ability. Being able to
quickly spin up a local, empty set of databases for things like integration testing can be a powerful
addition to the developer's toolkit. Running tests in the same form they will run in CI on a local
environment can save hours of waiting for feedback that could have been addressed before creating the
first PR.
We provide a schema file that you can edit and use to validate your JSON files in places such as CI or GitHub Actions to prevent downstream issues. You can specify which things are optional and which are required, such as requiring every table to have at least one index if that is your policy. You can also remove support for things you do not want used in your product, such as XML Indexes or Full Text Indexes. It is one more layer of automation that can help maintain consistency beyond simple human review.
Templates are like the class definition for your database. They define the tables and other objects that should exist in each "instance" or database for that template. Whether your server has one database that matches the template or 100... SchemaQuench identifies them based on the script you provide and updates each one to match the template definition. One run of SchemaQuench updates all the templates and all the associated databases for each template in the template order specified in the product.json file.
There are times when complex dependencies exist between templates... A chicken/egg relationship
that may have developed over time. The update process requires defining the order that templates
will be deployed, but what if a database needs certain objects to exist ahead of time, due to circular
dependencies? Your choice is to maintain some form of "startup" script to create the empty database
and then add those initial dependencies... OR you could define a pre template that only
applies those special dependent objects.
You can define a template for things like master or msdb to apply server
level objects and scripts such as jobs or server configurations. The order they appear in the
product.json will determine the order they get applied to your server. You might even have two
templates that refer to the master database where one applies before and one at the end.
It is best if any given object only exists in one template for a given database, but there is no restriction
that will prevent you from having different versions of the same object that apply in some sequence.
Keep in mind that it should be a LAST resort and include plenty of comments to help people understand
that more than one version exists in different places and why.
Script Tokens allow configuring certain values by environment to simplify your deployments. Update a few token values and change things like specific database names. They also allow you to specify things like minimum versions to be used in your version validation scripts and the new version to stamp in the version stamp scripts. These tokens are defined at the product level and can be used in the product and template scripts located in those JSON files.
See the SchemaQuench Walkthrough to help you get started with the tool.
drop if exists. In a future release the script can be deleted from source control.If you have a specific need that is not addressed, please reach out to our master craftsman and YouTube spokesman Forge Barrett. He will attempt to provide guidance or put the item up for consideration on our roadmap.
